Brief Function Introduction:
The GE 531X305NTBANG1 is a specialized terminal board designed for seamless integration into exciter or drive cabinets, offering versatile functionality including regulated and unregulated power supplies, encoder interfaces, and relay outputs.
Product Specifications:
| Model Number: | 531X305NTBANG1 |
| OEM: | GE Motors and Industrial Systems |
| Product Type: | Terminal Board |
| Power Supplies: | 5 VDC, 15 VDC (Regulated); 24 VDC, 125 VAC (Unregulated) |
| Encoder Compatibility: | 5 V, 15 V |
| Relay Outputs: | 7, comprised of form A or form C |
| Contacts Rating: | 120 VAC |
| Analog Inputs/Outputs: | Scalable using 4 potentiometers |
| Installation Parameters: | Included with the board |
| Switch Components: | 7 toggles |
| Relay Components: | DS2E M DC24V H300, 6 left-side, 1 right-edge |
| Inductor Coils: | 2 |
| Potentiometers: | 4 |
| Header Connectors: | Various sizes, 3 |
| Jumper Switches: | 24 |
| Pin Cable Connectors: | 3, 2 male, 1 female |
| Signal Interface: | Digital control inputs, relay outputs, low-level analog inputs/outputs, analog tach coarse scaling, power supply, encoder, RS-232C, RS-422 serial interfaces |
Product Details:
The GE 531X305NTBANG1 Terminal Board is engineered for industrial-grade reliability, featuring robust components and interfaces tailored for efficient operation within exciter or drive cabinets.
Equipped with advanced signal processing capabilities, this board delivers precise power regulation and encoder interfacing, ensuring smooth and accurate control in demanding industrial environments.
The inclusion of 7 relay outputs, rated for 120 VAC, enables flexible control over various systems, making it an indispensable part of complex industrial setups.
Adaptability is at the heart of the GE 531X305NTBANG1, thanks to its adjustable analog inputs and outputs, which are scaled using four potentiometers. This feature allows for customization to meet specific application requirements.
Designed with ease of installation in mind, the board comes equipped with all necessary parameters and interfaces, minimizing setup time and complexity. Its compact yet comprehensive design ensures optimal space utilization in confined cabinet environments.
